THI 3-0522
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 3W
PDF
/
Buying Options
Total Price: USD $29.04
Unit Price: USD $29.03697
≥1 USD $29.03697
≥10 USD $27.39337
≥100 USD $25.8428
≥500 USD $24.38
≥1000 USD $23
≥3000 USD $21.69811
Inventory: 6365
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 24-DIP Module, 8 Leads
Technical
Operating Temperature -40°C~75°C
Published 2014
Series THI 3 (3W)
Size / Dimension 1.25Lx0.80W x 0.41 H 31.8mmx20.3mmx10.5mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Power (Watts) 3W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Efficiency 60%
Voltage - Isolation 4kV
Voltage - Input (Max) 5.5V
Voltage - Output 1 12V
Voltage - Input (Min) 4.5V
Current - Output (Max) 125mA 125mA
Voltage - Output 2 -12V
Compliance
RoHS Status ROHS3 Compliant
