THB 6-4812
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 12V 6W
PDF
/
Buying Options
Total Price: USD $54.29
Unit Price: USD $54.28651
≥1 USD $54.28651
≥10 USD $51.21369
≥100 USD $48.3148
≥500 USD $45.58
≥1000 USD $43
≥3000 USD $40.56604
Inventory: 3382
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 20.3mm
Technical
Total Power Output-Max 6W
Current - Output (Max) 500mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 12V
Output Voltage 15V
Voltage - Input (Max) 75V
Voltage - Isolation 3kV
Efficiency 80%
Number of Outputs 1
JESD-30 Code R-PDMA-T7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Additional Feature SEATED HGT CALCULATED
Power (Watts) 6W
Applications ITE (Commercial), Medical
Terminal Finish GOLD
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
JESD-609 Code e4
Size / Dimension 1.25Lx0.80W x 0.47 H 31.8mmx20.3mmx12.0mm
Series THB 6 (6W)
Published 2009
Operating Temperature -40°C~71°C With Derating
Physical
Surface Mount NO
Package / Case 24-DIP Module, 5 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
