THB 6-1223
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 6W
PDF
/
Buying Options
Total Price: USD $44.7
Unit Price: USD $44.698689
≥1 USD $44.698689
≥10 USD $42.168576
≥100 USD $39.781672
≥500 USD $37.529877
≥1000 USD $35.405553
Inventory: 3687
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 31.8mm
Technical
Total Power Output-Max 6W
Voltage - Output 2 -15V
Current - Output (Max) 200mA 200mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 9V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 18V
Voltage - Isolation 3kV
Efficiency 78%
Number of Outputs 2
JESD-30 Code R-PDMA-T7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Power (Watts) 6W
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
Size / Dimension 1.25Lx0.80W x 0.47 H 31.8mmx20.3mmx12.0mm
Series THB 6 (6W)
Published 2009
Operating Temperature -40°C~71°C With Derating
Physical
Surface Mount NO
Package / Case 24-DIP Module, 6 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
