THB 10-4811
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 5.1V 10W
PDF
/
Inventory: 8219
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 5-DIP Module, 4 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~75°C With Derating
Published 2013
Series THB 10 (10W)
Size / Dimension 2.00Lx1.00W x 0.47 H 50.8mmx25.4mmx12.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Power (Watts) 10W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code R-PDMA-P5
Number of Outputs 1
Efficiency 76%
Voltage - Isolation 4kV
Voltage - Input (Max) 75V
Output Voltage 5.1V
Voltage - Output 1 5.1V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 2A
Dimensions
Length 50.8mm
Width 25.4mm
Compliance
RoHS Status ROHS3 Compliant
