THB 10-2423
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 10W
PDF
/
Inventory: 7853
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 50.8mm
Technical
Total Power Output-Max 10W
Voltage - Output 2 -15V
Current - Output (Max) 333mA 333mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 36V
Voltage - Isolation 4kV
Efficiency 82%
Number of Outputs 2
JESD-30 Code R-PDMA-P5
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Power (Watts) 10W
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
Size / Dimension 2.00Lx1.00W x 0.47 H 50.8mmx25.4mmx12.0mm
Series THB 10 (10W)
Published 2013
Operating Temperature -40°C~75°C With Derating
Physical
Surface Mount NO
Package / Case 5-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
