THB 10-2422 image
Favorite
THB 10-2422 image
Favorite

THB 10-2422

Traco Power
RoHS
RoHS RoHS compliant
Package 5-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER +/-12V 10W
PDF
/
Buying Options
Total Price: USD $58.77
Unit Price: USD $58.7664
≥1 USD $58.7664
≥10 USD $57.78608
≥100 USD $55.951808
≥500 USD $53.200048
≥1000 USD $49.531064
≥3000 USD $45.408
Inventory: 58
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length 50.8mm

Technical

Total Power Output-Max 10W
Voltage - Output 2 -12V
Current - Output (Max) 417mA 417mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 36V
Voltage - Isolation 4kV
Efficiency 81%
Number of Outputs 2
JESD-30 Code R-PDMA-P5
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Power (Watts) 10W
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
Size / Dimension 2.00Lx1.00W x 0.47 H 50.8mmx25.4mmx12.0mm
Series THB 10 (10W)
Published 2013
Operating Temperature -40°C~75°C With Derating

Physical

Surface Mount NO
Package / Case 5-DIP Module
Mounting Type Through Hole

Supply Chain

Factory Lead Time 11 Weeks
