TES 2N-4813

Traco Power
RoHS
RoHS RoHS compliant
Package 16-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 15V 2W
PDF
/
Inventory: 1829
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length 24mm
Height Seated (Max) 8.25mm

Technical

Total Power Output-Max 2.025W
Current - Output (Max) 135mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 79%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XDMA-G6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Subcategory Other Analog ICs
Power (Watts) 2W
Applications ITE (Commercial)
Terminal Finish Tin (Sn)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature SCP
JESD-609 Code e3
Size / Dimension 0.94Lx0.54W x 0.36 H 24.0mmx13.7mmx9.3mm
Series TES 2N (2W)
Published 2010
Operating Temperature -40°C~85°C With Derating

Physical

Surface Mount YES
Package / Case 16-SMD Module, 6 Leads
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
