TES 2-2423M
RoHS
RoHS compliant
RoHS compliantPackage 16-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 2W
PDF
/
Buying Options
Total Price: USD $27.9
Unit Price: USD $27.9048
≥1 USD $27.9048
≥10 USD $25.8676
≥100 USD $25.463328
≥500 USD $24.250864
≥1000 USD $22.230032
≥3000 USD $21.82583
Inventory: 21
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SMD Module, 6 Leads
Surface Mount YES
Technical
Operating Temperature -25°C~80°C With Derating
Series TES 2M (2W)
Size / Dimension 0.94Lx0.54W x 0.36 H 24.0mmx13.7mmx9.3mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Power (Watts) 2W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-G6
Number of Outputs 2
Efficiency 75%
Voltage - Isolation 4kV
Voltage - Input (Max) 26.4V
Output Voltage 15V
Voltage - Output 1 15V
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 66mA 66mA
Voltage - Output 2 -15V
Total Power Output-Max 2W
Dimensions
Height Seated (Max) 9.45mm
Width 13.7mm
Compliance
RoHS Status ROHS3 Compliant
