TEQ 20-7213WIR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER 15V 20W
PDF
/
Inventory: 4911
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Chassis Mount
Surface Mount NO
Technical
Operating Temperature -40°C~93°C With Derating
Series TEQ 20WIR (20W)
Size / Dimension 4.06Lx2.25W x 1.03 H 103.1mmx57.2mmx26.2mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 7
ECCN Code EAR99
Type Enclosed
Applications ITE (Commercial), Railway
Power (Watts) 20W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-MXMA-X7
Number of Outputs 1
Efficiency 87%
Voltage - Isolation 2.25kV
Voltage - Input (Max) 160V
Output Voltage 15V
Voltage - Output 1 15V
Voltage - Input (Min) 43V
Input Voltage-Nom 110V
Trim/Adjustable Output NO
Current - Output (Max) 1.33A
Compliance
RoHS Status ROHS3 Compliant
