TEQ 100-2416WIR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER 28V 101W
PDF
/
Inventory: 2605
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Chassis Mount
Surface Mount NO
Technical
Operating Temperature -40°C~105°C
Published 2014
Series TEQ 100WIR (100W)
Size / Dimension 4.06Lx3.50W x 3.45 H 103.1mmx88.9mmx87.6mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 12
ECCN Code EAR99
Type Enclosed
Applications Industrial, ITE (Commercial), Railway
Power (Watts) 101W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 1
Approval Agency CB, cULus, cURus
Efficiency 90%
Voltage - Isolation 2.25kV
Voltage - Input (Max) 36V
Output Voltage 28V
Voltage - Output 1 28V
Voltage - Input (Min) 10V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Current - Output (Max) 3.6A
Compliance
RoHS Status ROHS3 Compliant
