TEP 150-7218WI
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER 48V 154W
PDF
/
Buying Options
Total Price: USD $239.87
Unit Price: USD $239.87062
≥1 USD $239.87062
≥10 USD $226.29304
≥100 USD $213.484
≥500 USD $201.4
≥1000 USD $190
≥3000 USD $179.24528
Inventory: 2500
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Chassis Mount
Surface Mount NO
Technical
Operating Temperature -40°C~75°C
Published 2009
Series TEP 150WI (150W)
Size / Dimension 3.86Lx2.07W x 1.60 H 98.0mmx52.6mmx40.6mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Enclosed
Applications ITE (Commercial), Railway
Power (Watts) 154W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-MXFM-X9
Number of Outputs 1
Approval Agency CB, cURus
Efficiency 88%
Voltage - Isolation 2.25kV
Voltage - Input (Max) 160V
Output Voltage 48V
Voltage - Output 1 48V
Voltage - Input (Min) 43V
Input Voltage-Nom 110V
Trim/Adjustable Output YES
Current - Output (Max) 3.2A
Compliance
RoHS Status ROHS3 Compliant
