TEN 8-4812
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 12V 8W
PDF
/
Buying Options
Total Price: USD $27.82
Unit Price: USD $27.8168
≥1 USD $27.8168
≥10 USD $27.2184
≥100 USD $26.793184
≥500 USD $25.517536
≥1000 USD $23.391016
≥3000 USD $22.965712
Inventory: 35
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 20.3mm
Length 32mm
Technical
Total Power Output-Max 7.98W
Current - Output (Max) 666mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 87%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PDMA-P9
Pin Count 23/9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Power (Watts) 8W
Applications ITE (Commercial)
Terminal Finish Nickel (Ni)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, SCP
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Series TEN 8 (8W)
Published 2006
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount NO
Package / Case 24-DIP Module, 9 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
