TEN 3-2422WIN
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 3W
PDF
/
Buying Options
Total Price: USD $14.55
Unit Price: USD $14.5464
≥1 USD $14.5464
≥10 USD $14.32728
≥100 USD $14.107104
≥500 USD $13.666224
≥1000 USD $12.343672
≥3000 USD $12.123232
Inventory: 997
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 24-DIP Module, 8 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Published 2014
Series TEN 3WIN (3W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 8
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 3W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-P8
Number of Outputs 2
Efficiency 82%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 125mA 125mA
Voltage - Output 2 -12V
Total Power Output-Max 3W
Dimensions
Height Seated (Max) 10.7mm
Length 31.8mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
