TEN 25-1222
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 30W
PDF
/
Buying Options
Total Price: USD $65.97
Unit Price: USD $65.9736
≥1 USD $65.9736
≥10 USD $57.81424
≥100 USD $55.978912
≥500 USD $53.225744
≥1000 USD $49.555088
≥3000 USD $45.43
Inventory: 52
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 40.6mm
Length 50.8mm
Height Seated (Max) 10mm
Technical
Total Power Output-Max 30W
Voltage - Output 2 -12V
Current - Output (Max) 1.25A 1.25A
Trim/Adjustable Output YES
Input Voltage-Nom 12V
Voltage - Input (Min) 9V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 18V
Voltage - Isolation 1.5kV
Efficiency 88%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-MDMA-P7
Pin Count 7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Subcategory Other Analog ICs
Power (Watts) 30W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Not For New Designs
Pbfree Code yes
Feature Remote On/Off, OCP, OVP, SCP
Size / Dimension 2.00Lx1.60W x 0.37 H 50.8mmx40.6mmx9.5mm
Series TEN 25 (30W)
Published 2010
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount NO
Package / Case 7-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
