TEN 20-2423WI
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 20W
PDF
/
Buying Options
Total Price: USD $74.18
Unit Price: USD $74.18344
≥1 USD $74.18344
≥10 USD $69.98438
≥100 USD $66.023
Inventory: 83
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 7-DIP Module
Technical
Operating Temperature -40°C~85°C With Derating
Published 2005
Series TEN 20WI (20W)
Size / Dimension 2.00Lx1.60W x 0.40 H 50.8mmx40.6mmx10.2mm
Feature Remote On/Off, OCP, OVP, SCP
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 20W
Additional Feature -15 VOLT ADDITIONAL OUTPUT IS AVAILABLE
Subcategory Other Analog ICs
Technology HYBRID
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 15V
Voltage - Output 1 15V
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Current - Output (Max) 665mA 665mA
Voltage - Output 2 -15V
Dimensions
Height Seated (Max) 10.7mm
Length 50.8mm
Compliance
RoHS Status ROHS3 Compliant
