TEM 3-0523N
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 12 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 3W
PDF
/
Inventory: 2605
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 24-DIP Module, 12 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~85°C With Derating
Published 2013
Series TEM 3N (3W)
Size / Dimension 1.26Lx0.79W x 0.39 H 32.0mmx20.0mmx10.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 12
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 3W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Efficiency 78%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 5.5V
Output Voltage 15V
Voltage - Output 1 15V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Current - Output (Max) 100mA 100mA
Voltage - Output 2 -15V
Total Power Output-Max 3W
Dimensions
Height Seated (Max) 10.5mm
Compliance
RoHS Status ROHS3 Compliant
