TEC 3-2421WI

Traco Power
RoHS
RoHS RoHS compliant
Package 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER +/-5V 3W
PDF
/
Buying Options
Total Price: USD $12.62
Unit Price: USD $12.62477
≥1 USD $12.62477
≥10 USD $11.91016
≥100 USD $11.236
≥500 USD $10.6
≥1000 USD $10
≥3000 USD $9.43396
Inventory: 6831
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 9.1mm
Height Seated (Max) 11.7mm

Technical

Total Power Output-Max 3W
Voltage - Output 2 -5V
Current - Output (Max) 300mA 300mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Input (Max) 36V
Voltage - Isolation 1.6kV
Efficiency 79%
Number of Outputs 2
JESD-30 Code R-PSMA-T7
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Power (Watts) 3W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.1mmx11.2mm
Series TEC 3WI (3W)
Operating Temperature -40°C~90°C With Derating

Physical

Surface Mount NO
Package / Case 8-SIP Module, 7 Leads
Mounting Type Through Hole

Supply Chain

Factory Lead Time 13 Weeks
