TEC 2-4823
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 2W
PDF
/
Buying Options
Total Price: USD $9.83
Unit Price: USD $9.8296
≥1 USD $9.8296
≥10 USD $9.67648
≥100 USD $9.527936
≥500 USD $9.230144
≥1000 USD $8.336944
≥3000 USD $8.188083
Inventory: 36
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9.1mm
Height Seated (Max) 11.7mm
Technical
Total Power Output-Max 2W
Voltage - Output 2 -15V
Current - Output (Max) 67mA 67mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 75V
Voltage - Isolation 1.6kV
Efficiency 83%
Number of Outputs 2
JESD-30 Code R-PSMA-T7
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.1mmx11.2mm
Series TEC 2 (2W)
Operating Temperature -40°C~95°C With Derating
Physical
Surface Mount NO
Package / Case 8-SIP Module, 7 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
