TDN 5-4821WISM
RoHS
RoHS compliant
RoHS compliantPackage 7-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-5V 5W
PDF
/
Buying Options
Total Price: USD $26.27
Unit Price: USD $26.268
≥1 USD $26.268
≥10 USD $25.3132
≥100 USD $24.917376
≥500 USD $23.73096
≥1000 USD $21.753424
≥3000 USD $21.357882
Inventory: 1197
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Surface Mount
Package / Case 7-SMD Module, 6 Leads
Surface Mount YES
Technical
Operating Temperature -40°C~75°C With Derating
Series TDN 5WISM (5W)
Size / Dimension 0.52Lx0.36W x 0.40 H 13.2mmx9.1mmx10.2mm
Feature Remote On/Off, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 5W
Additional Feature ALSO OPERTAES WITH -5 VDC
Technology HYBRID
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-F6
Number of Outputs 2
Efficiency 80%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 75V
Output Voltage 5V
Voltage - Output 1 5V
Voltage - Input (Min) 18V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 500mA 500mA
Voltage - Output 2 -5V
Total Power Output-Max 5W
Dimensions
Height Seated (Max) 10.7mm
Width 9.1mm
Compliance
RoHS Status ROHS3 Compliant
