TDN 5-2421WI
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-5V 5W
PDF
/
Buying Options
Total Price: USD $24.16
Unit Price: USD $24.1648
≥1 USD $24.1648
≥10 USD $23.79168
≥100 USD $23.419616
≥500 USD $22.30448
≥1000 USD $20.445744
≥3000 USD $20.073997
Inventory: 158
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Through Hole
Package / Case 7-DIP Module, 6 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~75°C With Derating
Published 2015
Series TDN 5WI (5W)
Size / Dimension 0.52Lx0.36W x 0.40 H 13.2mmx9.1mmx10.2mm
Feature Remote On/Off, SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 5W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-T6
Number of Outputs 2
Efficiency 80%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 36V
Output Voltage 5V
Voltage - Output 1 5V
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 500mA 500mA
Voltage - Output 2 -5V
Total Power Output-Max 5W
Dimensions
Height Seated (Max) 10.7mm
Width 9.1mm
Compliance
RoHS Status ROHS3 Compliant
