TDL 2-4822 image
Favorite
TDL 2-4822 image
Favorite

TDL 2-4822

Traco Power
RoHS
RoHS RoHS compliant
Package 7-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER +/-12V 2W
PDF
/
Inventory: 7219
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 14mm
Length 14mm

Technical

Total Power Output-Max 2W
Voltage - Output 2 -12V
Current - Output (Max) 83mA 83mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 84%
Number of Outputs 2
JESD-30 Code S-XDMA-P5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Power (Watts) 2W
Applications ITE (Commercial)
Terminal Finish Tin (Sn)
Type Isolated Module
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
JESD-609 Code e3
Size / Dimension 0.55Lx0.55W x 0.31 H 14.0mmx14.0mmx8.0mm
Series TDL 2 (2W)
Operating Temperature -40°C~70°C

Physical

Surface Mount NO
Package / Case 7-DIP Module, 5 Leads
Mounting Type Through Hole

Supply Chain

Factory Lead Time 13 Weeks
