TCL 012-124 DC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTER 24V 24W
PDF
/
Buying Options
Total Price: USD $78.79
Unit Price: USD $78.7864
≥1 USD $78.7864
≥10 USD $76.32152
≥100 USD $73.859456
≥500 USD $67.704384
≥1000 USD $65.488544
≥3000 USD $60.94
Inventory: 72
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Total Power Output-Max 24W
Current - Output (Max) 1A
Trim/Adjustable Output YES
Input Voltage-Nom 12V
Voltage - Input (Min) 9.5V
Voltage - Output 1 24V
Output Voltage 24V
Voltage - Input (Max) 18V
Voltage - Isolation 1.5kV
Efficiency 86%
Approval Agency CB, cULus
Number of Outputs 1
JESD-30 Code X-XXMA-X6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Power (Watts) 24W
Applications Industrial, ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 3.94Lx1.06W x 2.95 H 100.1mmx26.9mmx74.9mm
Series TCL-DC (24 ~ 60W)
Published 2012
Operating Temperature -25°C~70°C With Derating
Physical
Surface Mount NO
Mounting Type DIN Rail
Supply Chain
Factory Lead Time 6 Weeks
