TPSM53604RDAR
RoHS
RoHS compliant
RoHS compliantPackage 14-PowerBQFN Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVRTR 36VIN 1-7VOUT 4A
PDF
/
Buying Options
Total Price: USD $6.31
Unit Price: USD $6.31238
≥1 USD $6.31238
≥10 USD $5.95508
≥100 USD $5.618
≥500 USD $5.3
≥1000 USD $5
Inventory: 1572
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5.5mm
Technical
Switcher Configuration BUCK
Control Technique PULSE WIDTH MODULATION
Control Features Enable, Active High
Current - Output (Max) 4A
Input Voltage-Nom 12V
Voltage - Input (Min) 3.8V
Voltage - Output 1 1V~7V
Voltage - Input (Max) 36V
Efficiency 95%
Number of Outputs 1
Base Part Number TPSM53604
Number of Functions 1
Terminal Form NO LEAD
Terminal Position UNSPECIFIED
Applications ITE (Commercial)
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Non-Isolated PoL Module
Number of Terminations 15
Moisture Sensitivity Level (MSL) 3
Part Status Active
Pbfree Code yes
Feature Adjustable Output
JESD-609 Code e4
Size / Dimension 0.22Lx0.20W x 0.16 H 5.5mmx5.0mmx4.1mm
Operating Temperature -40°C~105°C
Physical
Surface Mount YES
Package / Case 14-PowerBQFN Module
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
