TPS82697SIPT
RoHS
RoHS compliant
RoHS compliantPackage 8-BGA Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Conv DC-DC 1-OUT Step Down 2.3V 4.8V 8-Pin uSIP T/R
PDF
/
Buying Options
Total Price: USD $2.74
Unit Price: USD $2.7368
≥1 USD $2.7368
≥10 USD $2.45784
≥100 USD $2.323904
≥500 USD $2.013968
Inventory: 192
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 950μm
Width 2.3mm
Length 2.9mm
Height 1mm
Technical
Switching Frequency 3.3MHz
Switcher Configuration BUCK
Control Technique PULSE WIDTH MODULATION
Control Mode VOLTAGE-MODE
Quiescent Current 23μA
Input Voltage-Nom 3.6V
Voltage - Input (Min) 2.3V
Operating Supply Voltage 4.8V
Max Output Current 800mA
Output Voltage 2.8V
Voltage - Input (Max) 4.8V
Efficiency 95%
Number of Outputs 1
Pin Count 8
Base Part Number TPS82697
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Additional Feature ALSO HAS A CONTROL TECHNIQUE OF PFM
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature OCP, OTP, SCP, UVLO
Size / Dimension 0.12Lx0.09W x 0.04 H 3.0mmx2.4mmx1.0mm
Series MicroSip?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-BGA Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 12 Weeks
Alternative Model
