TPS82676SIPT
RoHS
RoHS compliant
RoHS compliantPackage 8-BGA Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER 1.1V 0.66W
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.596
≥1 USD $2.596
≥10 USD $2.332
≥100 USD $2.199648
≥500 USD $1.874224
Inventory: 597
Minimum: 1
-
+
Technical Details
Technical
Max Output Voltage 1.1V
Control Mode VOLTAGE-MODE
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Switcher Configuration BUCK
Nominal Output Voltage 1.1V
Switching Frequency 5.45MHz
Control Features Enable, Active High
Output Current 600mA
Input Voltage-Nom 3.6V
Voltage - Input (Min) 2.3V
Max Output Current 600mA
Output Type Fixed
Output Voltage 1.1V
Voltage - Input (Max) 4.8V
Efficiency 90%
Number of Outputs 1
Pin Count 8
Base Part Number TPS82676
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Subcategory Switching Regulator or Controllers
Additional Feature ALSO HAS CONTROL TECHNIQUE OF PFM
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OTP, UVLO
Size / Dimension 0.12Lx0.09W x 0.04 H 3.0mmx2.4mmx1.0mm
Series MicroSip?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Height 1mm
Length 2.9mm
Width 2.3mm
Thickness 950μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Package / Case 8-BGA Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 12 Weeks
