TPS826716SIPT
RoHS
RoHS compliant
RoHS compliantPackage 8-BGA Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 1.6V
PDF
/
Buying Options
Total Price: USD $2.57
Unit Price: USD $2.5696
≥1 USD $2.5696
≥10 USD $2.31
≥100 USD $2.183808
≥500 USD $1.892616
Inventory: 712
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 950μm
Width 2.3mm
Length 2.9mm
Height 1mm
Technical
Switching Frequency-Max 6000kHz
Switcher Configuration BUCK
Control Technique PULSE WIDTH MODULATION
Control Mode VOLTAGE-MODE
Control Features Enable, Active High
Quiescent Current 17μA
Current - Output (Max) 600mA
Input Voltage-Nom 3.6V
Voltage - Input (Min) 2.3V
Voltage - Output 1 1.6V
Output Voltage 1.8V
Voltage - Input (Max) 4.8V
Efficiency 90%
Number of Outputs 1
Base Part Number TPS826716
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Additional Feature ALSO OPERATES IN PFM CONTROL TECHNIQUE
Applications ITE (Commercial)
Type Non-Isolated PoL Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature OCP, OTP, UVLO
Size / Dimension 0.12Lx0.09W x 0.04 H 3.0mmx2.4mmx1.0mm
Series MicroSip?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-BGA Module
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 12 Weeks
