PTV05020WAH
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 0.8-3.6V 18A
PDF
/
Buying Options
Total Price: USD $60.41
Unit Price: USD $60.412369
≥1 USD $60.412369
≥10 USD $56.992795
≥100 USD $53.766796
≥500 USD $50.723397
≥1000 USD $47.852252
Inventory: 3372
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mounting Type Through Hole
Package / Case 12-SIP Module
Surface Mount NO
Number of Pins 12
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PTV05020W
Size / Dimension 1.75Lx0.37W x 0.50 H 44.5mmx9.4mmx12.7mm
JESD-609 Code e3
Feature UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Non-Isolated PoL Module
Terminal Finish Tin (Sn)
Applications ITE (Commercial)
HTS Code 8504.40.95.80
Max Power Dissipation 64.8W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Number of Functions 1
Depth 8.64mm
Base Part Number TV05020
Number of Outputs 1
Efficiency 94%
Voltage - Input (Max) 5.5V
Output Voltage 3.6V
Max Output Current 18A
Voltage - Output 1 0.8V~3.6V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output YES
Output Current 18A
Output Power 64.8W
Max Output Voltage 3.6V
Current - Output 1 18A
Min Output Voltage 800mV
Isolation Non-Isolated
Dimensions
Height 12.95mm
Thickness 12.7mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
