PTQA430033P2AZ image
Favorite
PTQA430033P2AZ image
Favorite

PTQA430033P2AZ

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-SMD Module, 1/4 Brick
Category Power Supplies - Board Mount / DC DC Converters
Description Isolated DC/DC Converters 100W 48V Input Iso DC-DC Converter
PDF
/
Inventory: 7526
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Number of Outputs 1
Efficiency 92%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 3.3V
Max Output Current 30A
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Output Current 30A
Output Power 100W
Max Output Voltage 3.63V
Current - Output 1 30A
Min Output Voltage 2.64V
Pin Count 8
Base Part Number TQA430033
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 100W
Applications ITE (Commercial)
Terminal Finish TIN SILVER COPPER
Type Isolated Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Feature Remote On/Off, OCP, OTP, OVP, UVLO
JESD-609 Code e1
Size / Dimension 2.22Lx1.45W x 0.50 H 56.4mmx36.8mmx12.7mm
Series PTQA430033 (100W)
Packaging Tray
Operating Temperature -40°C~85°C

Dimensions

Height 12.7mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead

Physical

Number of Pins 8
Surface Mount NO
Package / Case 8-SMD Module, 1/4 Brick
Mounting Type Surface Mount
