PTQA430025N2AZ
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 1/4 Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 100W 48V Input Iso DC-DC Converter
PDF
/
Inventory: 2180
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 12.7mm
Technical
Min Output Voltage 2V
Current - Output 1 30A
Max Output Voltage 2.75V
Output Power 75W
Output Current 30A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 30A
Output Voltage 2.5V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 91%
Number of Outputs 1
Pin Count 8
Base Part Number TQA430025
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 75W
Power (Watts) 100W
Applications ITE (Commercial)
Terminal Finish TIN SILVER COPPER
Type Isolated Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Feature Remote On/Off, OCP, OTP, OVP, UVLO
JESD-609 Code e1
Size / Dimension 2.22Lx1.45W x 0.50 H 56.4mmx36.8mmx12.7mm
Series PTQA430025 (100W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Surface Mount NO
Package / Case 8-SMD Module, 1/4 Brick
Mounting Type Surface Mount
