PTN78060WAS
RoHS
/
Package 7-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
3-A, Wide-Input, Adjustable Switching egulator Module 7-Surface Mount Module -40 to 85
PDF
/
Buying Options
Total Price: USD $17.77
Unit Price: USD $17.7672
≥1 USD $17.7672
≥10 USD $17.6264
≥100 USD $17.49
≥500 USD $17.216954
≥1000 USD $16.39697
≥3000 USD $15.030646
Inventory: 353
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 8.75mm
Height 9mm
Technical
Min Input Voltage (DC) 7V
Max Input Voltage (DC) 36V
Isolation Non-Isolated
Switching Frequency-Max 660kHz
Switcher Configuration BUCK
Min Output Voltage 2.5V
Current - Output 1 3A
Max Output Voltage 12.6V
Output Power 45W
Max Voltage Rating (DC) 36V
Output Current 3A
Input Voltage-Nom 20V
Voltage - Output 1 2.5V~12.6V
Max Output Current 3A
Output Voltage 12.6V
Efficiency 94%
Number of Outputs 1
Base Part Number PTN78060
Depth 15.75mm
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position DUAL
Max Power Dissipation 38W
Subcategory Power Supply Modules
HTS Code 8504.40.95.80
Additional Feature REMOTE SHUTDOWN
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature Remote On/Off, OCP, OTP, UVLO
Size / Dimension 1.00Lx0.62W x 0.38 H 25.4mmx15.7mmx9.7mm
Series PTN78060W
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 7
Surface Mount NO
Package / Case 7-SMD Module
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
