PTN78060HAH
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 11.85-22V
PDF
/
Buying Options
Total Price: USD $22.2
Unit Price: USD $22.2024
≥1 USD $22.2024
≥10 USD $22.0352
≥100 USD $21.86448
≥500 USD $21.522846
≥1000 USD $20.497893
≥3000 USD $18.789795
Inventory: 317
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 8.75mm
Height 9mm
Technical
Min Input Voltage (DC) 15V
Max Input Voltage (DC) 36V
Nominal Output Voltage 22V
Isolation Non-Isolated
Switching Frequency-Max 660kHz
Max Output Power 45W
Switcher Configuration BUCK
Min Output Voltage 11.85V
Current - Output 1 3A
Control Technique PULSE WIDTH MODULATION
Max Output Voltage 22V
Output Power 45W
Output Current 3A
Input Voltage-Nom 20V
Voltage - Output 1 11.85V~22V
Max Output Current 3A
Output Voltage 22V
Efficiency 96%
Number of Outputs 1
Pin Count 7
Base Part Number PTN78060
Depth 15.75mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 45W
HTS Code 8504.40.95.80
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature UVLO
JESD-609 Code e3
Size / Dimension 1.00Lx0.62W x 0.35 H 25.4mmx15.7mmx8.9mm
Series PTN78060H
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 7
Surface Mount NO
Package / Case 7-DIP Module
Mounting Type Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
Alternative Model
