PTN78020AAH
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER -15 TO -3V
PDF
/
Buying Options
Total Price: USD $26.16
Unit Price: USD $26.1624
≥1 USD $26.1624
≥10 USD $25.95824
≥100 USD $25.75672
≥500 USD $24.14698
≥1000 USD $22.13464
≥3000 USD $21.732225
Inventory: 364
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 8.75mm
Height 9mm
Technical
Min Input Voltage (DC) 9V
Max Input Voltage (DC) 29V
Isolation Non-Isolated
Switching Frequency-Max 660kHz
Max Output Power 25W
Min Output Voltage -15V
Current - Output 1 4A
Control Technique PULSE WIDTH MODULATION
Topology Boost
Max Output Voltage -3V
Output Power 25W
Output Current 4A
Input Voltage-Nom 20V
Voltage - Output 1 -15V~-3V
Max Output Current 4A
Output Voltage -3V
Efficiency 87%
Number of Outputs 1
Base Part Number PTN78020
Depth 22.1mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 25W
Power Rating 25W
HTS Code 8504.40.95.80
Applications ITE (Commercial)
Terminal Finish Tin (Sn)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OTP, UVLO
JESD-609 Code e3
Size / Dimension 1.50Lx0.87W x 0.36 H 38.1mmx22.1mmx9.1mm
Series PTN78020A (25W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 7
Surface Mount NO
Package / Case 7-DIP Module
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 20 hours ago)
Factory Lead Time 6 Weeks
Alternative Model
