PTN78000HAS
RoHS
/
Package SMD/SMT
Category Power Supplies - Board Mount / DC DC Converters
Description
1.5 A, Wide Input, Wide Output Adjust Module 5-Surface Mount Module -40 to 85
PDF
/
Buying Options
Total Price: USD $12.3
Unit Price: USD $12.3024
≥1 USD $12.3024
≥10 USD $12.21088
≥100 USD $12.1176
≥500 USD $11.931392
≥1000 USD $11.558351
≥3000 USD $10.439854
Inventory: 606
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 8.25mm
Width 12.57mm
Length 18.92mm
Height 8.5mm
Technical
Power - Output 22.5W
Switching Frequency-Max 660kHz
Switcher Configuration BUCK
Min Output Voltage 11.85V
Current - Output 1 1.5A
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 36V
Min Input Voltage 15V
Voltage - Output 22V
Max Output Voltage 22V
Current - Output 1.5A
Power Dissipation-Max 33W
Analog IC - Other Type SWITCHING REGULATOR
Temperature Grade INDUSTRIAL
Input Voltage-Nom 20V
Voltage - Output 1 22V
Max Output Current 1.5A
Efficiency 94 %
Number of Outputs 1
Pin Count 5
Number of Functions 1
Terminal Form BALL
Terminal Position DUAL
Technology HYBRID
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3
Feature OCP, OTP, UVLO
JESD-609 Code e0
Physical
Number of Pins 5
Surface Mount YES
Package / Case SMD/SMT
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Alternative Model
