PTMA403033A2AZT
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 48VIN 3A 3.3V 5SMD
PDF
/
Inventory: 2222
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 9.144mm
Technical
Min Output Voltage 3V
Current - Output 1 3A
Max Output Voltage 3.6V
Output Power 10W
Output Current 3A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 3.3V
Max Output Current 3A
Output Voltage 3.3V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 82%
Number of Outputs 1
Pin Count 5
Base Part Number PTMA403033
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 9.9W
Applications ITE (Commercial)
Terminal Finish TIN SILVER COPPER
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Feature OCP, OVP, UVLO
JESD-609 Code e1
Size / Dimension 1.10Lx0.96W x 0.36 H 27.9mmx24.4mmx9.1mm
Series PTMA40xx (10W)
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 5
Surface Mount NO
Package / Case 5-SMD Module
Mounting Type Surface Mount
