PTMA402050A2AS

Texas Instruments
RoHS
/
Package 5-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description CONV DC-DC 48VIN 2A 5V SMD
PDF
/
Inventory: 6860
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Height 9.144mm

Technical

Min Output Voltage 4.5V
Current - Output 1 2A
Max Output Voltage 5.5V
Output Power 10W
Output Current 2A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 2A
Output Voltage 5V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 85%
Number of Outputs 1
Pin Count 5
Base Part Number PTMA402050
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 10W
Applications ITE (Commercial)
Terminal Finish TIN LEAD
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature OCP, OVP, UVLO
JESD-609 Code e0
Size / Dimension 1.10Lx0.96W x 0.36 H 27.9mmx24.4mmx9.1mm
Series PTMA40xx (10W)
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Number of Pins 5
Surface Mount NO
Package / Case 5-SMD Module
Mounting Type Surface Mount
