PTMA401120P1AZT
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 48VIN 1A 12V 5SMD
PDF
/
Inventory: 9262
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 5-SMD Module
Surface Mount NO
Number of Pins 5
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series PTMA40xx (10W)
Size / Dimension 1.10Lx0.96W x 0.36 H 27.9mmx24.4mmx9.1mm
JESD-609 Code e1
Feature OCP, OVP, UVLO
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Terminal Finish TIN SILVER COPPER
Applications ITE (Commercial)
Power (Watts) 10W
Max Power Dissipation 12W
Technology HYBRID
Terminal Position DUAL
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number PTMA401120
Pin Count 5
Number of Outputs 1
Efficiency 87%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 12V
Max Output Current 1A
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Output Current 1A
Output Power 12W
Max Output Voltage 13.2V
Current - Output 1 1A
Min Output Voltage 10.8V
Dimensions
Height 9.144mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
