PTMA401120N2AD image
Favorite
PTMA401120N2AD image
Favorite

PTMA401120N2AD

Texas Instruments
RoHS
RoHS RoHS compliant
Package 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 12V 10W
PDF
/
Buying Options
Total Price: USD $32.82
Unit Price: USD $32.817143
≥1 USD $32.817143
≥10 USD $30.959566
≥100 USD $29.207139
≥500 USD $27.553906
≥1000 USD $25.994247
Inventory: 1168
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Thickness 8.25mm
Height 8.5mm

Technical

Isolation Isolated
Min Output Voltage 10.8V
Current - Output 1 1A
Max Output Voltage 13.2V
Output Power 12W
Output Current 1A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 1A
Output Voltage 12V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 82%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 6
Base Part Number PTMA401120
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 24.38mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 12W
Power Rating 12W
Power (Watts) 10W
Applications ITE (Commercial)
Terminal Finish Tin (Sn)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Feature UVLO
JESD-609 Code e3
Size / Dimension 1.10Lx0.96W x 0.34 H 27.9mmx24.4mmx8.6mm
Series PTMA40xx (10W)
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Number of Pins 6
Surface Mount NO
Package / Case 6-DIP Module
Mounting Type Through Hole

Supply Chain

Lifecycle Status NRND (Last Updated: 2 days ago)
