PTH12060LAST
RoHS
/
Package 10-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
0.8 to 1.8V 10-A, 12-V Input Non-Isolated Wide-Adjust Module 10-Surface Mount Module -40 to 85
PDF
/
Buying Options
Total Price: USD $23.3
Unit Price: USD $23.2959
≥1 USD $23.2959
≥10 USD $19.11495
≥100 USD $18.5174
≥500 USD $17.91985
≥1000 USD $17.32325
Inventory: 1124
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 8.75mm
Length 25.27mm
Height 9mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 300kHz
Min Output Voltage 800mV
Current - Output 1 10A
Control Mode VOLTAGE-MODE
Protections OUTPUT OVER CURRENT;THERMAL
Max Output Voltage 1.8V
Output Power 18W
Output Current 10A
Trim/Adjustable Output YES
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Voltage - Output 1 0.8V~1.8V
Max Output Current 10A
Output Voltage 1.8V
Voltage - Input (Max) 13.2V
Efficiency 88%
Approval Agency UL, CSA
Number of Outputs 1
Pin Count 10
Base Part Number TH12060
Depth 15.27mm
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 18W
Subcategory Power Supply Modules
Additional Feature REMOTE SHUTDOWN
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature Remote On/Off, OCP, UVLO
Size / Dimension 1.00Lx0.62W x 0.38 H 25.4mmx15.7mmx9.7mm
Series PTH12060
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 10
Surface Mount NO
Package / Case 10-SMD Module
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 8 Weeks
