PTH12030LAZ
RoHS
RoHS compliant
RoHS compliantPackage 13-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 0.8-1.8V 47W
PDF
/
Buying Options
Total Price: USD $37.18
Unit Price: USD $37.18
≥1 USD $37.18
≥10 USD $36.88608
≥100 USD $36.595354
≥500 USD $35.433473
≥1000 USD $33.6908
≥3000 USD $31.367274
Inventory: 39
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 13-SMD Module
Surface Mount NO
Number of Pins 13
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PTH12030
Size / Dimension 1.37Lx1.12W x 0.38 H 34.8mmx28.5mmx9.6mm
JESD-609 Code e1
Feature Remote On/Off, OCP, OTP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 13
ECCN Code EAR99
Type Non-Isolated PoL Module
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Applications ITE (Commercial)
Additional Feature REMOTE SHUTDOWN
HTS Code 8504.40.85.00
Subcategory Power Supply Modules
Max Power Dissipation 47W
Technology HYBRID
Terminal Position QUAD
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Depth 28.45mm
Base Part Number TH12030
Pin Count 13
Number of Outputs 1
Approval Agency UL, CSA
Efficiency 89%
Voltage - Input (Max) 13.8V
Output Voltage 1.8V
Max Output Current 26A
Voltage - Output 1 0.8V~1.8V
Voltage - Input (Min) 10.2V
Input Voltage-Nom 12V
Trim/Adjustable Output YES
Output Current 26A
Max Output Voltage 1.8V
Protections OUTPUT OVER CURRENT;THERMAL
Control Mode VOLTAGE-MODE
Current - Output 1 26A
Total Power Output-Max 26W
Min Output Voltage 800mV
Isolation Non-Isolated
Dimensions
Height 9mm
Length 34.8mm
Thickness 8.75mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
