PTH08T250WAZ
RoHS
RoHS compliant
RoHS compliantPackage 22-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
MOD PIP 50A .7-3.6V HORZ 22SMD
PDF
/
Buying Options
Total Price: USD $69.26
Unit Price: USD $69.256
≥1 USD $69.256
≥10 USD $68.71568
≥100 USD $68.17448
≥500 USD $66.010208
≥1000 USD $62.763888
≥3000 USD $58.435344
Inventory: 115
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 9.64mm
Height 9.64mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 14V
Isolation Non-Isolated
Switching Frequency-Max 750kHz
Max Output Power 180W
Min Output Voltage 700mV
Current - Output 1 50A
Control Mode VOLTAGE-MODE
Protections OUTPUT OVER CURRENT;THERMAL
Max Output Voltage 3.6V
Output Power 180W
Output Current 50A
Trim/Adjustable Output YES
Input Voltage-Nom 12V
Voltage - Output 1 0.7V~3.6V
Max Output Current 50A
Output Type Adjustable
Output Voltage 3.6V
Efficiency 94%
Approval Agency UL, CSA
Number of Outputs 1
Base Part Number TH08T250
Depth 38.61mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 180W
Subcategory Power Supply Modules
HTS Code 8504.40.85.00
Additional Feature REMOTE SHUTDOWN
Applications ITE (Commercial)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 22
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OTP, UVLO
JESD-609 Code e1
Size / Dimension 1.52Lx1.02W x 0.40 H 38.6mmx25.9mmx10.2mm
Series PTH08T250W
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 22
Surface Mount YES
Package / Case 22-SMD Module
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
Alternative Model
