PTH05020WAD
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Texas Instruments PTH05020WAD, DC-DC Power Supply Module 5 V Input,, 10-pin, DIP Module
PDF
/
Buying Options
Total Price: USD $21.46
Unit Price: USD $21.45575
≥1 USD $21.45575
≥10 USD $17.6054
≥100 USD $17.05535
≥500 USD $16.5053
≥1000 USD $15.9543
Inventory: 1204
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Through Hole
Package / Case 10-DIP Module
Surface Mount NO
Number of Pins 10
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PTH05020W
Size / Dimension 1.50Lx0.87W x 0.35 H 38.1mmx22.1mmx8.9mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Type Non-Isolated PoL Module
Terminal Finish Tin (Sn)
Applications ITE (Commercial)
Additional Feature REMOTE SHUTDOWN
Subcategory Power Supply Modules
Max Power Dissipation 79.2W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
Depth 22.1mm
Base Part Number TH05020
Pin Count 10
Number of Outputs 1
Approval Agency UL, CSA
Efficiency 95%
Voltage - Input (Max) 5.5V
Output Voltage 3.6V
Max Output Current 22A
Voltage - Output 1 0.8V~3.6V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output YES
Output Current 22A
Max Output Voltage 3.6V
Protections OUTPUT OVER CURRENT;THERMAL
Control Mode VOLTAGE-MODE
Current - Output 1 22A
Total Power Output-Max 72.6W
Min Output Voltage 800mV
Switching Frequency-Max 300kHz
Isolation Non-Isolated
Dimensions
Height 9mm
Length 37.97mm
Thickness 8.75mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
