PTH04T220WAZ
RoHS
RoHS compliant
RoHS compliantPackage 11-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
16-A, 2.2-V to 5.5-V Input, Non-Isolated, Wide-Output, Adjustable Power Module with TurboTrans 11-Surface Mount Modul...
PDF
/
Buying Options
Total Price: USD $18.27
Unit Price: USD $18.2688
≥1 USD $18.2688
≥10 USD $18.12976
≥100 USD $17.98896
≥500 USD $17.708064
≥1000 USD $16.864989
≥3000 USD $15.459611
Inventory: 62
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 8.5mm
Length 25.27mm
Height 0m
Technical
Isolation Non-Isolated
Switching Frequency-Max 400kHz
Min Output Voltage 690mV
Current - Output 1 16A
Control Mode VOLTAGE-MODE
Protections OUTPUT OVER CURRENT;THERMAL
Max Output Voltage 3.6V
Output Current 16A
Trim/Adjustable Output YES
Input Voltage-Nom 5V
Voltage - Input (Min) 2.2V
Voltage - Output 1 0.69V~3.6V
Max Output Current 16A
Output Voltage 3.6V
Voltage - Input (Max) 5.5V
Efficiency 94%
Approval Agency UL, CSA
Number of Outputs 1
Pin Count 11
Base Part Number TH04T220
Depth 18.92mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 58W
Subcategory Power Supply Modules
HTS Code 8504.40.85.00
Applications ITE (Commercial)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 11
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OTP, UVLO
JESD-609 Code e1
Size / Dimension 1.00Lx0.75W x 0.36 H 25.4mmx19.1mmx9.1mm
Series PTH04T220W
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Weight 5.3g
Number of Pins 11
Surface Mount YES
Package / Case 11-SMD Module
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
Alternative Model
