PTH04040WAZ
RoHS
RoHS compliant
RoHS compliantPackage 20-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 0.8V to 2.5V 60A 20-Pin DIP Module
PDF
/
Buying Options
Total Price: USD $54.75
Unit Price: USD $54.7536
≥1 USD $54.7536
≥10 USD $54.3224
≥100 USD $53.89487
≥500 USD $52.183754
≥1000 USD $49.61733
≥3000 USD $46.195389
Inventory: 97
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 8.82mm
Height 9.07mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 975kHz
Current - Output 1 60A
Control Mode VOLTAGE-MODE
Protections OUTPUT OVER CURRENT;THERMAL
Output Current 60A
Trim/Adjustable Output YES
Input Voltage-Nom 3.3V
Voltage - Input (Min) 2.95V
Voltage - Output 1 0.8V~2.5V
Max Output Current 60A
Output Voltage 2.5V
Voltage - Input (Max) 5.5V
Efficiency 93%
Approval Agency UL, CSA
Number of Outputs 1
Pin Count 20
Base Part Number TH04040
Depth 26.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 150W
Subcategory Power Supply Modules
HTS Code 8504.40.85.00
Applications ITE (Commercial)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature Remote On/Off, OCP, OTP, UVLO
JESD-609 Code e1
Size / Dimension 2.05Lx1.05W x 0.38 H 52.1mmx26.7mmx9.7mm
Series PTH04040W
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 20
Package / Case 20-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
Alternative Model
