PTB78560BAS
RoHS
/
Package 11-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 1.8-3.6V 30W
PDF
/
Buying Options
Total Price: USD $136.14
Unit Price: USD $136.136098
≥1 USD $136.136098
≥10 USD $128.430278
≥100 USD $121.160641
≥500 USD $114.302489
≥1000 USD $107.832534
Inventory: 4491
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Thickness 9.73mm
Height 9.98mm
Technical
Current - Output 2 8A
Isolation Isolated
Min Output Voltage 1.8V
Current - Output 1 8A
Voltage - Output 2 3.6V
Max Output Voltage 3.6V
Output Power 30W
Output Current 8A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 1.8V~3.6V
Max Output Current 8A
Output Voltage 3.3V
Voltage - Input (Max) 60V
Voltage - Isolation 1.5kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 11
Base Part Number PTB78560
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 26.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 235; 260
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 30W
Power Rating 30W
Additional Feature OPERATES WITH A 48 V INPUT NOMINAL
Applications ITE (Commercial)
Terminal Finish Tin/Lead (Sn/Pb)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 11
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
Feature Remote On/Off, OCP, OTP, UVLO
JESD-609 Code e0
Size / Dimension 2.04Lx1.04W x 0.40 H 51.8mmx26.5mmx10.3mm
Series PTB78560 (30W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 11
Surface Mount NO
Package / Case 11-SMD Module
Mounting Type Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 5 days ago)
