PTB48510CAH
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC-DC +-15V 2.2A HORZ T/H
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 12.45mm
Width 36.83mm
Length 56.39mm
Height 12.7mm
Technical
Current - Output 2 2.2A
Isolation Isolated
Min Output Voltage 14.5V
Current - Output 1 2.2A
Voltage - Output 2 -15V
Max Output Voltage 15.5V
Output Power 66W
Output Current 6.5A
Current - Output (Max) 2.2A 2.2A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 15V
Max Output Current 2.2A
Output Voltage 5V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 90%
Number of Outputs 2
Pin Count 8
Base Part Number PTB48510
Depth 36.83mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 66W
Power Rating 66W
Applications ITE (Commercial)
Terminal Finish Tin (Sn)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e3
Series PTB4851x
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Surface Mount NO
Package / Case 8-DIP Module
Mounting Type Through Hole
Supply Chain
Lifecycle Status NRND (Last Updated: 4 days ago)
