PTB48500AAH

Texas Instruments
RoHS
RoHS RoHS compliant
Package 10-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description Module DC-DC 2-OUT 3.3V/1.2V 6A/7A 19.8W/8.4W 10-Pin DIP Module Tray
PDF
/
Buying Options
Total Price: USD $57.22
Unit Price: USD $57.2176
≥1 USD $57.2176
Inventory: 91
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 11.938mm

Technical

Current - Output 2 7A
Isolation Isolated
Current - Output 1 6A
Voltage - Output 2 1.2V
Output Power 28W
Output Current 6A
Current - Output (Max) 6A 7A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 6A
Output Voltage 3.3V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 82%
Number of Outputs 2
JESD-30 Code R-XDMA-P6
Pin Count 10
Base Part Number PTB48500
Depth 36.83mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 28W
Power Rating 28W
Applications ITE (Commercial)
Terminal Finish TIN
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 2.22Lx1.45W x 0.47 H 56.4mmx36.8mmx12.0mm
Series PTB4850x
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Number of Pins 10
Surface Mount NO
Package / Case 10-DIP Module
Mounting Type Through Hole
