PT8123A
RoHS
RoHS compliant
RoHS compliantPackage 31-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 12VIN 30A PROG HORZ
PDF
/
Buying Options
Total Price: USD $48.9
Unit Price: USD $48.9016
≥1 USD $48.9016
Inventory: 170
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 38.1mm
Length 91.4mm
Height 11.9mm
Technical
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Current 30A
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Voltage - Output 1 0.8V~1.575V
Max Output Current 30A
Output Voltage 1.575V
Voltage - Input (Max) 13.2V
Efficiency 82%
Number of Outputs 1
Pin Count 31
Base Part Number PT8123
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 47.3W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 31
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Excalibur? PT8120
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Weight 55g
Package / Case 31-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
