PT8103C
RoHS
RoHS compliant
RoHS compliantPackage 31-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters 1.075-1.85V 40A 3.3V Inp Multiph Prog ISR
PDF
/
Buying Options
Total Price: USD $416.63
Unit Price: USD $416.634435
≥1 USD $416.634435
≥10 USD $402.934656
≥25 USD $400.133724
≥50 USD $397.352258
≥100 USD $389.179487
≥500 USD $361.35514
Inventory: 1356
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 38.1mm
Length 91.44mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Power 70.3W
Output Current 39A
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3.1V
Voltage - Output 1 1.075V~1.85V
Max Output Current 40A
Output Voltage 1.85V
Voltage - Input (Max) 3.6V
Efficiency 86%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 31
Base Part Number PT8103
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Depth 41.14mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 74W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 31
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
Series Excalibur? PT8100
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 31
Package / Case 31-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
