PT79SR109V
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR -9V -1.5A 3PSIP VERT
PDF
/
Inventory: 988
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 23.876mm
Technical
Switcher Configuration BUCK
Control Mode VOLTAGE-MODE
Voltage - Input (Min) -13V
Max Output Current 1.5A
Output Voltage -9V
Voltage - Input (Max) -30V
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSMA-T3
Pin Count 3
Base Part Number 79SR109
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 13.5W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OTP, SCP
Size / Dimension 0.90Lx0.31W x 0.94 H 22.9mmx7.9mmx23.9mm
Series PT79SR100
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Weight 7g
Package / Case 3-SIP Module
Mounting Type Through Hole
Mount Through Hole
