PT79SR108S
RoHS
RoHS compliant
RoHS compliantPackage 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER -8V 1.5A
PDF
/
Buying Options
Total Price: USD $429.01
Unit Price: USD $429.009712
≥1 USD $429.009712
≥10 USD $414.903014
≥25 USD $412.018882
≥50 USD $409.154799
≥100 USD $400.739271
≥500 USD $372.088463
Inventory: 5044
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 8.636mm
Technical
Switcher Configuration BUCK
Min Output Voltage -8V
Current - Output 1 1.5A
Control Mode VOLTAGE-MODE
Topology Boost
Max Output Voltage -8V
Output Current -1.5A
Voltage - Input (Min) -12V
Max Output Current -1.5A
Output Voltage -8V
Voltage - Input (Max) -30V
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
Base Part Number 79SR108
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 23.62mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 12W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature OTP, SCP
Size / Dimension 0.94Lx0.90W x 0.34 H 23.9mmx22.9mmx8.6mm
Series PT79SR100
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Weight 7g
Number of Pins 3
Surface Mount YES
Package / Case 3-SMD Module
Mounting Type Surface Mount
